IP20 LED Light Strip,SPI SK6812 Dynamic Pixel RGB effect

Pixel RGB LED Strip Light

SKU Code:WJ-LLS-120P-RGB-D-24V
Size:FPCB 10mm
Bend Direction:Vertical Bend Only
Min Bend:80mm
Material:FPCB+LED
Color:Dynamic Pixel RGB
Voltage:24V
LED Type:SMD5050, IC: SK6812, Epistar
CRI:90
IP Rating:IP20

Product Details

Pixel RGB
SKU:WJ-LLS-120P-RGB-D-24V
Color Temp Red: 624.9nm White: 6500K
(Color mixing)
Green: 525.6nm
Blue: 469.4nm
Watts/m(24V ) Red: 8.44 W White: 21.91 W
(Color mixing)
Green: 9.01 W
Blue: 9.02 W
Lumen/m(24V) Red: 178.62 lm White: 707.84 lm
(Color mixing)
Green: 518.00 lm
Blue: 96.17 lm
Unit Cut(24V) 5cm
Max Loading(24V) 5m
LED Quantity(m) 120 LEDs + 20 IC

PDF Download File
